Description
About the IMC IE-MiniMc
Measuring less than 3.5 inches deep and 2 inches wide, the IE-MiniMc Series converters are some of the industry’s smallest copper-to-fiber media converters, with both data connections on the same side. The IE-MiniMc family of media converters are a fraction of the cost of other industrial grade alternatives. These products provide the ease and convenience of plug-and-play operation with features including Auto Negotiation and Auto-Cross.
Multiple powering options include Power over Ethernet (PoE/PD), AC wall adapter and USB, which offers unsurpassed flexibility for a variety of installations.
General Information |
|
| Manufacturer | Advantech Co., Ltd |
| Manufacturer Part Number | 854-19722 |
| Brand Name | B+B SmartWorx |
| Product Line | IE-MiniMc |
| Product Name | Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
Interfaces/Ports |
|
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| DVI | No |
| USB | No |
| Parallel Port | No |
| Digital Audio | No |
| Digital Audio/Video | No |
| Management Port | No |
| Number of Network (RJ-45) Ports | 1 |
| Number of ST Ports | 1 |
Media & Performance |
|
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Maximum Distance Supported | 5 km |
| Fiber Optic Cable Core/Cladding Specification |
|
Network & Communication |
|
| Ethernet Technology | Fast Ethernet |
| Network Technology | 10/100Base-TX |
Physical Characteristics |
|
| Form Factor |
|
| Height | 0.8″ |
| Width | 1.8″ |
| Depth | 3.4″ |
Miscellaneous |
|
| Certifications & Standards |
IEEE Standards:
|
