Description
- Mfr Part Number:BK021
- Features:
- Virtually inaudible Silent Wings 135mm PWM fan
- Achieves only 21.4dB(A) at maximum fan speed
- Six high-performance copper heat pipes
- Airflow-optimized, wave-contoured cooling fins
- Easily installable black installation kit can be mounted from above
- Supports an additional 120mm fan; clips are included in scope of delivery
- Brushed aluminum top cover with diamond cut finish
- German product conception, design and quality control
- Socket Type:
- Intel:LGA 1150 / 1151 / 1155 / 1156 / 1366 / 2011(-3) Square ILM / 2066
- AMD:Socket AM2(+) / AM3(+) / AM4 / FM1 / FM2(+)
- Fan:
- Model:Silent Wings 135mm PWM
- Speed:1400 RPM@ 100% PWM
- Noise Level:50% RPM – 10.5 dBA, 75% RPM – 15.6 dBA, 100% RPM – 21.4 dBA
- Rated Voltage:12 V
- Input Current:0.11 A
- Input Power:1.32 W
- Bearing Type:Fluid Dynamic Bearing
- Motor:6-pole Fan Motor
- Connector:4 Pin PWM
- Cable Length:220 mm
- Life Expectancy:300,000 hours @ 25C
- Dimensions:135.0 x 135.0 x 22.0 mm
- Heatsink:
- Heat Pipes Number / Diameter:6x 6 mm
- Material:Copper Base / Aluminum Fins
- Number of Fins:51
- CPU Contact Surface:CNC machined
- Surface Treatment:Aluminum / black ceramic spray painted
- Dimensions(W x L x H):136.0 x 159.4 x 74.3 mm
- Thermal Design Power:200 W
- Dimensions (WxLxH):136.0 x 159.4 x 96.3 mm (Overall) (w/o mounting material)
- Weight:0.92 kg
