Description
ComNet 10/100 Mbps Ethernet Media Converter – Two Independent Channels
The ComNet™ CNFE2MC Ethernet and CNFE22MC media converters are designed to transmit and receive 10/100 Mbps data over optical fiber through user selectable SFP options. These models require the ordering of sold-separately interchangeable SFP modules for fiber type, distance and connectors. The CNFE2MC transmits and receives a single channel of Ethernet data and the CNFE22MC transmits and receives two independent channels in one unit. The electrical interface will Auto-Negotiate to a 10 Mbps, or 100 Mbps Ethernet rate without any adjustments. The optical interface operates at a 100 Mbps Ethernet rate. Both are environmentally hardened to operate in extreme temperatures. LED indicators are provided for confirming equipment operating status. Packaged in the exclusive ComNet ComFit housing, the CNFE2MC and CNFE22MC units may be either wall or rackmounted, or may be DIN-rail mounted by the addition of ComNet model DINBKT1 adaptor plate.
- Connect different types of media within a network with this single port
- With Twisted Pair cable, get the desired data transfer rate up to a required distance
- With 10/100Base-TX technology get up to 100Mbps data transfer rate over twisted pair cable
- Rack mounting enables you to organize wires & secure cables for professional installation
Product Type: Transceiver/Media Converter
Environmentally Friendly: Yes
Environmental Certification: WEEE
Country Of Origin: United States
Brand Name: ComNet
Form Factor: Rail-mountable
Manufacturer: ACRE
Product Model: CNFE22MC
Product Name: 10/100 Mbps Ethernet Media Converter – Two Independent Channels
Manufacturer Part Number: CNFE22MC
Package Contents:
- 10/100 Mbps Ethernet Media Converter – Two Independent Channels
- Power Supply
Limited Warranty: Lifetime
General Information
| Manufacturer |
ACRE |
| Manufacturer Part Number |
CNFE22MC |
| Brand Name |
ComNet |
| Product Model |
CNFE22MC |
| Product Name |
10/100 Mbps Ethernet Media Converter – Two Independent Channels |
| Product Type |
Transceiver/Media Converter |
| UPC |
0845770001068 |
| Ethernet Technology |
Fast Ethernet |
| Height |
1.1″ |
| Width |
2.5″ |
| Depth |
3.3″ |
Miscellaneous
| Package Contents |
- 10/100 Mbps Ethernet Media Converter – Two Independent Channels
- Power Supply
|
| Environmentally Friendly |
Yes |
Warranty
| Limited Warranty |
Lifetime |
