Description
About the HighPoint RocketMate 110 RM110
The RocketMate 110 is a stand-alone, external M.2 NVMe enclosure designed for use with USB 3.2 20G connectivity.The USB Type-C connector accepts HighPoint Certified USB-C to Type-C cables (such as the USB-C31-1MC) , and can be connected to any industry standard USB 3.2 controller, such as the HighPoint RocketU 1411C, RocketU 1444C, or RocketU 1488C.
High-Performance 20Gb/s USB 3.2 Inerface
The RocketMate 110’s unique PCIe Gen3 to USB 3.2 20Gb/s architecture can deliver over 2000MB/s via a 3.2/3.1/3.0 or Thunderbolt 3 host connection. The Type-C connector is compatible with industry-standard USB 3.2/3.1/3.0 Type-C ports and Thunderbolt 3 host platforms.
Supports Off-the-Shelf M.2 NVMe SSD’s
The RocketMate 110 can house any off the shelfPCIe Gen3 or Gen4 2242/2260/2280 M.2 NVMe SSD.
Rugged, All-Aluminum chassis Protects & Cools NVMe Media
The robust, compact enclosure allows you use M.2 SSDs like standard, portable USB drives.
The all aluminum construction efficiently transfers waste heat away from the NVMe hardware to promote the reliability and longevity of your M.2 SSDs.
Complete 20Gb/s NVMe Storage Solution!
RocketMate 110 + RocketU 1411C
Add 20G NVMe Storage + USB 3.2 connectivity to any PCIe 3.0 capable platform! The RocketMate 110 and RocketU 1411C are avaiable as a complete kit.
The RocketU 1411C provides dedicated 20Gb/s transfer bandwidth, and is capable of supporting any industry standard USB 3.x, 2.0 and 1.x device.
Need more than 20G?
RocketMate 110 + RocketU 1444C
Complete, Host-to-Device 8000MB/s USB to NVMe Connectivity Solution. Imagine Plug & Play USB Connectivity with the blazing performance of NVMe RAID Storage!
Customers can combine up to four RocketMate 110 enclosures with a single RocketU 1444C USB 3.2 HBA.
The RocketMate 110 is a stand-alone, external M.2 NVMe enclosure designed for use with USB 3.2 20G connectivity.The USB Type-C connector accepts HighPoint Certified USB-C to Type-C cables (such as the USB-C31-1MC) , and can be connected to any industry standard USB 3.2 controller, such as the HighPoint RocketU 1411C, RocketU 1444C, or RocketU 1488C.
High-Performance 20Gb/s USB 3.2 Inerface
The RocketMate 110’s unique PCIe Gen3 to USB 3.2 20Gb/s architecture can deliver over 2000MB/s via a 3.2/3.1/3.0 or Thunderbolt 3 host connection. The Type-C connector is compatible with industry-standard USB 3.2/3.1/3.0 Type-C ports and Thunderbolt 3 host platforms.
Supports Off-the-Shelf M.2 NVMe SSD’s
The RocketMate 110 can house any off the shelfPCIe Gen3 or Gen4 2242/2260/2280 M.2 NVMe SSD.
Rugged, All-Aluminum chassis Protects & Cools NVMe Media
The robust, compact enclosure allows you use M.2 SSDs like standard, portable USB drives.
The all aluminum construction efficiently transfers waste heat away from the NVMe hardware to promote the reliability and longevity of your M.2 SSDs.
Complete 20Gb/s NVMe Storage Solution!
RocketMate 110 + RocketU 1411C
Add 20G NVMe Storage + USB 3.2 connectivity to any PCIe 3.0 capable platform! The RocketMate 110 and RocketU 1411C are avaiable as a complete kit.
The RocketU 1411C provides dedicated 20Gb/s transfer bandwidth, and is capable of supporting any industry standard USB 3.x, 2.0 and 1.x device.
Need more than 20G?
RocketMate 110 + RocketU 1444C
Complete, Host-to-Device 8000MB/s USB to NVMe Connectivity Solution. Imagine Plug & Play USB Connectivity with the blazing performance of NVMe RAID Storage!
Customers can combine up to four RocketMate 110 enclosures with a single RocketU 1444C USB 3.2 HBA.
General Information |
|
| Manufacturer | HighPoint Technologies, Inc |
| Manufacturer Part Number | RM110 |
| Brand Name | HighPoint |
| Product Line | RocketMate 110 |
| Product Model | RM110 |
| Product Name | RocketMate 110 USB 3.2 20G to NVMe External Drive Enclosure |
| Product Type | Drive Enclosure |
Technical Information |
|
| Number of Solid State Drive Supported | 1 |
| Number of Solid State Drive Installed | 0 |
I/O Expansions |
|
| Number of Total Expansion Bays | 1 |
| Hot Swappable Bays | Yes |
Network & Communication |
|
| Wireless LAN | No |
Interfaces/Ports |
|
| Drive Interface | M.2 |
| Host Interface | USB 3.2 (Gen 2) Type C |
Software |
|
| Operating System Supported |
|
Physical Characteristics |
|
| Product Material | Aluminum |
| Form Factor | Portable |
| Height | 0.7″ |
| Width | 4.1″ |
| Depth | 2.1″ |
| Weight (Approximate) | 5.60 oz |
Miscellaneous |
|
| Package Contents |
|
| Compatibility |
|
| Green Compliant | Yes |
| Environmental Compliance |
|
Warranty |
|
| Limited Warranty | 1 Year |
