Description
About the Raritan Dominion PX2 PX2-5965X3-V2C5
Rack Power Distribution Units (PDUs)
The PX series boasts the most reliable and sophisticated rack PDUs on the market. It offers metering at the inlet, outlet, and PDU circuit breaker level. And tracks current, voltage, power, power factor, and energy usage within 1% billing-grade accuracy.In short, it helps you to better manage existing power capacity, and save energy.
But the PX series offers more than reliable power distribution and metering. It also supports sensors that ensure your equipment is operating in a safe environment. And remote outlet switching to ensure proper provisioning and avoid tripped circuit breakers.Or reboot hung servers.All without stepping foot in the data center.
We offer hundreds of models that meet all your needs. Whether you have a small, medium, or large data center; densely packed 400V three-phase racks; high power blade servers; or a lights-out colo deployment — there’s a PX just for you.See more reasons to consider the PX below.
General Information |
|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | PX2-5965X3-V2C5 |
| Brand Name | Raritan |
| Product Line | Dominion |
| Product Series | PX2 |
| Product Model | PX2-5965X3-V2C5 |
| Product Name | Dominion PX2-5965X3-V2C5 9-Outlet PDU |
| Packaged Quantity | 1 |
| Product Type | PDU |
Technical Information |
|
| Plug/Connector Type | NEMA L21-30P |
| Plug/Connector Detail | 3 x NEMA L21-30P |
| Receptacle Type | IEC 60320 C19 |
| Receptacle Detail | 9 x IEC 60320 C19 |
Power Description |
|
| Input Voltage | 230 V AC |
| Output Voltage | 208 V AC |
| Power Rating (VA) | 25.90 kVA |
| Input Current | 30 A |
Management |
|
| Management | Protocols:
|
Interfaces/Ports |
|
| Network (RJ-45) | Yes |
Physical Characteristics |
|
| Mount Type | Rack-mountable |
| Rack Height | 0U |
| Height | 70.1″ |
| Width | 1.8″ |
| Depth | 3.9″ |
Miscellaneous |
|
| Green Compliant | Yes |
| Country of Origin | Taiwan |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Warranty |
|
| Limited Warranty | 2 Year |
